| System interface | C-MAC® |
| Screen diagonal | 8" |
| Resolution | 1920 x 1200 px |
| Wide angle display | 160° |
| Video output | HDMI |
| Number of video inputs | 2 |
| USB port type | 2.0 |
| IP protection class | IP54 (splash-water protected) |
| Rechargeable battery, battery type | Chargeable Li-ion battery |
| Storage medium for documentation | SD card, transferable to USB flash drive |
| Battery operating time max. | 120 min |
| Power Management | Capacity indicator of chargeable Li-ion battery |
| Playback option | Captured images and video sequences |
| VESA mount | 75 x 75 mm |
| Screen width | 150 mm |
| Screen height | 94 mm |
| Length | 230 mm |
| Width | 155 mm |
| Depth | 57 mm |
| Weight | 1250 g |
| Input voltage | 12 V |
| Electrical protection class | II |
