Product details

35 Watt holmium:YAG Laser
Three different pulse modes are available.
In addition to predefined procedures, individual procedures can also be saved.
Touch screen control
The Laser is equipped with a fiber identification feature (RFID technology) to enable automatic fiber identification.
Fibers can be purchased for re-use or in sterile packaging.

Laser type	Pulsed Ho:YAG laser
Wavelength	2080 nm
Power P0 max.	35 Watt
Power Pp max.	10 kW
Repetition rate	4...30 Hz
Pulse duration	90-2000 µs
Pulse modes	Long pulse duration (450 µs…2000 µs), Short pulse duration (90 µs…450 µs), Burst mode (depending on individual setting)
Energy	0.2...4 Joules
Fiber connector	Modified SMA fiber connector
Automatic fiber detection	Yes (1)
Fiber identification technology	RFID system
Fiber diameter	230 µm, 365 µm, 600 µm
Divergence	0.22 mrad half-angle
Pilot laser	< 5 mW, 532 nm
Activation	One-pedal footswitch
Display	10" HD touch screen
Laser class	4
Power supply	100 – 240 VAC
Line frequency	50/60 Hz
Width	610 mm
Height	300 mm
Depth	430 mm
Weight	35 kg
Brand	CALCULASE III
